Package Contents

Before continuing, verify that the PEAK 980 package that you received is complete. Your package should have all the items listed in the following table.
Item Name
1 PEAK980 Serial MB
2 USB Cable ST:QW-6609013 USB CONx2+Bracket to Dupont 2x5P PIT:2.54mm L=300mm
3 SATA 7P 180D(Lock) to 7P 180D(Lock) 26AWG L:500mm
4 DB9(M)x2+Bracket to Housing 1x10P PIT:1.0mm L=250mm
Optional Accessories
Item Part Number
1 603DVI0008X00
Note: The heatspreader acts as a thermal coupling device to the module and is thermally coupled to the CPU via a thermal gap filler.
On some modules, it may also be thermally coupled to other heat generating components with the use of additional thermal gap fillers.
Although the heatspreader is the thermal interface where most of the heat generated by the module is dissipated, it is not to be considered
as a heatsink. It has been designed as a thermal interface between the module and the application specific thermal solution.
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.
Name
DVI-I Y cable
Qty
1
1
2
1
