Appendix G: Pin Definition for the Multiport and COM Cable
RS-232 (Tx/Rx) Connector
Connector location: P2
1
6
P0 Pin
P2 Pin
Definition
2
2
RXD3_R
7
3
TXD3_R
10
5
GND
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
5
9
CAN/GPIO Connector
Connector location: P3
1
6
P0 Pin
P3 Pin
3
1
4
4
8
8
9
3
12
7
13
2
14
5
15
6
71
5
9
Definition
GPIO1
GPIO4
CAN1_L
GPIO3
CAN1_H
GPIO2
GPIO5
GND
VTC 1020 and nROK 1020 Series User Manual
