Appendix G: Pin Definition for the Multiport and COM Cable

P0 Connector Pinout

1
11
Pin Definition
1 RXD_R_D
3 RXD1_R
5 GND
7 TXD_R_B
9 RS485A_+
11 RXD_R_D
13 RS485A_-
15 GND
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
5
15
Pin Definition
2 TXD2_R
4 RS485B_-
6 TXD_R_D
8 TXD1_R
10 GND
12 RXD2_R
14 RS485B_+

P1 to P6 Connector Pinouts

RS-232 (Tx/Rx) Connector

Connector location: P1
1
6
P0 Pin P1 Pin
1 2
5 5
6 3
73
5
9
Definition
RXD_R_D
GND
TXD_R_D
