Chapter 3: Jumpers and Connectors
WWAN/WLAN Module Selector
Connector location: SW4
1 2 3 4 5 6
For WWAN Wake-Up & Voice Functions on Mini-PCIe CN10
WWAN
HE910/LE910
Wake-Up & Voice*
SW4.1
On
SW4.2
Off
SW4.3
Off
SW4.4
On
Digital
HE910 (I2S)
Voice**
*Default Settings
**Digital voice is selectable in BIOS.
For WLAN LED on Mini-PCIe CN9
WLAN
(LED Low Active)
CE902A, DPE909-
AA*
SW4.5
On
SW4.6
Off
*Default Settings
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
WWAN
WWAN
SIM5360E
MC7304/MC7354
Wake-Up & Voice
Wake-Up & Voice
Off
Off
On
On
On
On
Off
Off
PCM
MC73xx(PCM)
WLAN
(LED High Active)
ZQ802XRACB,
Q802XRN6F
Off
On
Input Voltage Control Switch
Connector type: DIP switch
Connector location: SW3
1 2
Function
12V
24V
9~36V (Default)
*Default Settings
34
Definition
1 Off, 2 Off
1 Off, 2 On
*1 On, 2 On
