Service data
R 1500 R
Oil capacities
Engine (with filter)
Engine (without filter)
Transmission Initial filling
Transmission oil change
Rear wheel drive Initial filling/oil change
Valve clearances
Inlet
Exhaust
Ignition timing
Spark plugs
Electrode gap
Wear limit
Idle speed
Throttle cable setting
for cold-start (increased idle) speed
for throttle (twistgrip) cable
for divider cable
Brakes
Brake fluid
Colour of identification mark on brake calipers/brake pads, front
Minimum front pad thickness
Minimum rear pad thickness
Minimum front disc thickness
Minimum rear disc thickness
Tyre pressures
front
rear
Tightening torques
Oil filter
Engine oil drain plug
Gearbox oil filler plug
Gearbox oil drain plug
Rear wheel drive oil filler/drain plug
Fuel tank to rear frame
Fuel pump assembly to tank
Poly-V belt preload
Alternator to cover mount
Brake caliper fasteners, front
Brake caliper fasteners, rear
Rear wheel studs
Tightening cylinder heads
Nut
M 10 screw
Locknut, valve adjusting screw
Cylinder head cover
Spark plugs NGK BKR 7 EKC
Order No. 01 71 0 026 973
Item
UX-VS-2, 07.2000 1st edition
Desired value
3.75 (6.6)
3.5 (6.15)
approx. 1.0 (1.76)
up to lower edge
of filler hole
approx. 0.8 (1.41)
up to lower edge
of filler hole
approx. 0.25 (0.44)
up to lower edge
of filler hole
0.15 (0.006)
0.30 (0.012)
adjust at TDC
0.8 (0.0315)
1.0 (0.039)
±50
1,100
no play
play approx. 0.5 (0.02)
no play
green
1.0 (0.039)
1.0 (0.039) (wear mark)
4.5 (0.177)
4.5 (0.177)
2.2 - 2.5 (31.9 – 36.26)
2.5 - 2.9 (36.26 – 42.06)
11
32
30
30
23
22
5
8
20
30
40
105
unscrew / 20
180
unscrew / 40
8
8
25
Units / Specifications
litres (Imp. pints)
[SI 11 048 90]
litres (Imp. pints)
[SI 11 048 90]
litres (Imp. pints)
Brand-name hypoid gear oil, SAE
class GL 5 SAE 90
litres (Imp. pints)
Brand-name hypoid gear oil, SAE
class GL 5 SAE 90
litres (Imp. pints)
Brand-name hypoid gear oil, SAE
class GL 5 SAE 90
measured cold (max. 35 °C/95 °F)
mm (in)
mm (in)
static setting
mm (in)
mm (in)
rpm
mm (in)
DOT 4
mm (in)
mm (in)
mm (in)
mm (in)
depending on load
bar (psi)
bar (psi)
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
° tightening angle
Nm
Nm
Nm
Nm
BMW recommends Castrol
