Appendix H: Power Consumption
Item Device
S0 State
Core i3-
2
115GRE
28W
Full-run state + loading (PoE w/ 60W)
3 S3 State
4 IGN OFF
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Test Case
Idle state
Full-run state (Burn-In)
Full-run state + loading
Full state Sleep mode
Full state
IGNITION OFF
Average
Current(A)
12V 1.52
24V 0.85
36V 0.7
12V 3.25
24V 1.74
36V 1.32
12V 4.41
24V 2.33
36V 1.71
12V 9.95
24V 4.77
36V 3.21
12V 0.23
12V wake up 0.23
WWAN
12V 0.009
12V wake up 0.055
WWAN
24V 0.008
24V wake up
WWAN 0.035
36V 0.008
36V wake up
WWAN 0.028
77
Result
Maximum
Watt(W) Current(A)
18.24 3.21
20.4 1.75
25.2 1.28
39 3.82
41.76 2.09
47.52 1.52
52.92 4.93
55.92 2.52
61.56 1.88
119.4 10.45
114.48 5.08
115.56 3.37
2.75 N/A
2.76 N/A
0.108 N/A
0.66 N/A
0.192 N/A
0.84 N/A
0.288 N/A
1.008 N/A
Watt(W)
38.52
42
46.08
45.84
50.16
54.72
59.16
60.48
67.68
125.4
121.92
121.32
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
