Chapter 3: Jumpers and Connectors
VTC 7260-x/VTC 7260-xC4 Jumper/Switch/Expand slot on PCBA
This chapter describes the location and pinout assignment of the jumpers, slots, switched on VTC 7260 PCBA. The user can find out the slots
designed to be installed with the Wi-Fi modules, LTE/5G modules or Hailo AI card, etc.
Locations of the Jumpers and Connectors for the Motherboard
Top View
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
CN8
J1 (SATA PWR)
SW3
CN4 (SATA)
J5
SW4
J2 J3 J4
25
J10
J8 (COM3)
J9 (COM4)
CN17 (SIM2-1)
CN18 (SIM1-1)
SW5
J7 (RTC batt.)
CN15
SW6
VTC 7260 Series User Manual
