ZS5-4 Controller Hardware Overview
FIGURE 5
Callout
1
2
3
4
5
90 Oracle ZFS Storage Appliance Customer Service Manual • December 2016
ZS5-4 Internal Components (Exploded View)
Description
Power supplies
Power supply backplane board
SP card
System battery
HBA card
Callout Description
9 Memory riser card
10 Motherboard
11 Storage drive
12 Fan module
13 Fan board
