Replacing a ZS4-4 Fan Module

Replacing a ZS4-4 Fan Module
Caution -
effectiveness of the cooling system. For this reason, the replacement fan should be unpacked in
advance and ready to insert into the controller chassis as soon as the faulted fan is removed.
Fan modules cool the motherboard and its components. The fan modules are arranged in
stacked pairs (a front row and a back row) to provide redundancy. If you remove a failed fan
module, replace it immediately. Fan modules are hot-swappable and can be removed and
installed while the storage controller is running without affecting other hardware capabilities.
Use the following procedure to replace a ZS4-4 fan module.
To flash the locator LED on the chassis to service, go to Maintenance >
1.
Hardware in the BUI and click the associated locator icon
service processor (SP) prompt and enter set /SYS/LOCATE status=on
To locate the faulted component, go to Maintenance > Hardware > Fan and click
2.
the row with an amber indicator.
The component is highlighted in the diagram.
3. At the back of the controller, verify that cables have sufficient length and
clearance to extend the controller from the rack.
Extend the controller from the rack as described in
4.
Controller from the Rack" on page
5. Remove the top cover as described in
6. Lift the green handle at the top of the fan module to unlock the fan module, and
pull the fan module straight up and out.
Caution -
to the internal connector on the fan module board. When removing a fan module, do not rock it
back and forth.
Position the replacement fan module so the connector on the bottom of the
7.
module is aligned with the connector on the inside of the slot and all keying and
146 Oracle ZFS Storage Appliance Customer Service Manual • December 2016
Operating a controller for an extended period of time with fans removed reduces the
Excessive movement or rocking of the fan module during removal can cause damage
"Extending the Storage
53.
"Removing the Top Cover" on page
, or go to the
54.
