12. Connect data cables to the PCIe card, routing them through the cable
management arm.
13. When the system has finished booting, log in and set the time using the steps in
the task
Administration Guide, Release

ZS3-4 Controller Hardware Overview

To understand the ZS3-4, see the following topics:
"ZS3-4 Base Configuration" on page 201
■
"ZS3-4 Specifications" on page 201
■
"ZS3-4 Front and Rear Panel Components" on page 202
■
"ZS3-4 Internal Components" on page 206
■
"ZS3-4 PCIe I/O Cards" on page 212
■
"ZS3-4 Attached Storage" on page 216
■

ZS3-4 Base Configuration

The ZS3-4 controller can be configured as a standalone controller or clustered controllers to
create a high-availability cluster configuration. The following table describes the configuration
options:
TABLE 21
Mktg Part
Number
7105725
Refer to the product site at
recent component specification.

ZS3-4 Specifications

ZS3-4 Physical Specifications - The ZS3-4 controller chassis fits in a standard equipment rack,
and occupies three rack units (3RU) in height. The chassis dimensions are as follows:
"Setting Clock Synchronization (BUI)" in Oracle ZFS Storage Appliance
ZS3-4 Controller Features
CPU Memory
4x10-core, 1TB (16GB
2.40GHz DIMMs)
https://www.oracle.com/storage/nas/index.html
OS8.6.x.
Read Cache Boot Drive
SAS-2 SAS-2
Four 1.6TB Two 900GB
ZS3-4 Controller Hardware Overview
Software
HBA SAS-2
Version (min)
4X4-port 2013.1.0
for the most
Servicing the ZS3-4 Controller 201
