Servicing the ZS5-2 Controller

Be sure to read sections
"Prerequisites for Servicing Hardware" on page
Most hardware faults clear after replacing the affected component. If a fault does not self-clear,
see "Repairing Active Problems" on page
To replace ZS5-2 hardware components, use the following tasks:
"Replacing a ZS5-2 HDD" on page 103
■
"Replacing a ZS5-2 Fan Module" on page 106
■
"Replacing a ZS5-2 Power Supply" on page 111
■
"Replacing a ZS5-2 DIMM" on page 116
■
"Replacing or Adding a ZS5-2 PCle Card" on page 121
■
"Replacing a ZS5-2 System Battery" on page 123
■
To understand the ZS5-2 controller, use the following topics:
"ZS5-2 Configuration Options" on page 127
■
"ZS5-2 Front and Rear Panel Components" on page 128
■
"ZS5-2 Specifications" on page 131
■
"ZS5-2 Internal Components" on page 132
■
"ZS5-2 PCIe Card Configuration" on page 137
■
"ZS5-2 Cable Management Arm" on page 138
■
"ZS5-2 Attached Storage" on page 139
■

Replacing a ZS5-2 HDD

HDDs are hot-swappable and can be removed and installed while the storage controller is
running without affecting other hardware capabilities. Use the following procedure to replace a
ZS5-2 HDD. For information on disk compatibility, see the
"Getting Started with Servicing the Hardware" on page 17
51.
39.
and
Oracle Systems Handbook.
Servicing the ZS5-2 Controller 103
