7420 Controller Hardware Overview

14. Use a pen, or other pointed object, to press and release the recessed Power
button on the storage controller front panel. The Power/OK status indicator next
to the Power button lights and remains lit.
Connect data cables to the PCIe card, routing them through the cable
15.
management arm.
16. When the system has finished booting, log in and set the time using the steps in
the task
Administration Guide, Release
7420 Controller Hardware Overview
This section describes the internal and external components of the Oracle ZFS Storage 7420
controller. See the following for details:
"7420 Configuration Options" on page 306
■
"7420 Front and Back Panel Components" on page 307
■
"7420 Specifications" on page 310
■
"7420 Internal Components" on page 311
■
"7420 PCIe I/O Cards" on page 316
■
"7420 Attached Storage" on page 321
■

7420 Configuration Options

The Sun ZFS Storage 7420 Appliance consists of a standalone storage controller, or two
storage controllers in a high-availability cluster configuration, and one to 36 disk shelves. The
following table describes the 7420 configuration options:
Note -
TABLE 33
Product ID
7420 M2
7420 M2
306 Oracle ZFS Storage Appliance Customer Service Manual • December 2016
"Setting Clock Synchronization (BUI)" in Oracle ZFS Storage Appliance
7420 M2 controllers cannot be clustered with 7420 controllers.
7420 Controller Configuration Options
Mktg Part
CPU
Number
7107089 4x8-core, 2.0
GHz
7107090 4x10-core,
2.40GHz
OS8.6.x.
DIMMs Read Cache
8GB, 16GB 1.6TB SAS
8GB, 16GB 1.6TB SAS
Mfg Part
Boot Drive
Number
900GB SAS 7075466
900GB SAS 7075470
