ZS4-4 CPU and Memory
FIGURE 22
Figure
Legend
1
Memory riser card P3/MR1
2
Memory riser card P3/MR0
3
Memory riser card P2/MR1
4
Memory riser card P2/MR0
5
Memory riser card P1/MR1
6
Memory riser card P1/MR0
ZS4-4 Controller Hardware Overview
7
Memory riser card P0/MR1
8
Memory riser card P0/MR0
9
CPU P3
10
CPU P2
11
CPU P1
12
CPU P0
Servicing the ZS4-4 Controller
175
