Callout
Description
1
Motherboard
2
SP card
3
HBA card
4
Power supplies (2)
5
System battery
6
Power supply backplane
7
HBA SAS cables (2)
ZS5-4 Controller Hardware Overview
Callout
Description
8
Storage drive backplane board
9
Heatsinks and CPUs (4)
10
Memory riser cards (8)
11
Fan modules (6)
12
Fan board
13
Storage drive slots (2)
Servicing the ZS5-4 Controller
89
