ZS5-2 Controller Hardware Overview
TABLE 17
Status Indicator
Name
Activity
Link speed
Network Management Port
The ZS5-2 controller has one 10/100/1000BASE-T Ethernet management domain interface,
labeled NET MGT. There are two status indicators (LEDs) on this port. These indicators are
visible from the rear of the controller. The service processor NET MGT port is the optional
connection to the Oracle ILOM service processor. The NET MGT port is configured by default
to use Dynamic Host Configuration Protocol (DHCP). The service processor NET MGT port
uses an RJ-45 cable for a 10/100/1000BASE-T connection.
TABLE 18
Status Indicator
Name
Activity
Link speed
Serial Management Port
The service processor SER MGT port uses an RJ-45 cable and is the default connection to the
Oracle ILOM service processor. This port supports local connections to the server and only
recognizes Oracle ILOM command-line interface (CLI) commands. Typically you connect a
terminal or terminal emulator to this port.
Note -
130 Oracle ZFS Storage Appliance Customer Service Manual • December 2016
Gigabit Ethernet Port Status Indicators
Location
Top left
Top right
Network Management Port Status Indicators
Location
Top left
Top right
This port does not support network connections.
Color State and Meaning
Green ■ ON – No link
■ OFF– No activity
■ FLASHING – Packet activity
Bicolored: Amber/ ■ OFF – 100BASE-T link
Green
■ Amber ON – 1000BASE-T link
■ Green ON – 10GBASE-T link
Color State and Meaning
Amber ■ ON – Link up
■ OFF – No link or down link
■ FLASHING – Packet activity
Green ■ Green ON – 1000BASE-T link
■ OFF – 10/100BASE-T link
