1. Identify the PCIe card slot location.
If replacing a faulted PCIe card, identify the PCIe card to be replaced.
■
Go to the Maintenance > Hardware section of the BUI, click the right-arrow icon for the
controller, click Slot, and note the ID of the faulted PCIe card, which has an amber icon.
If replacing a non-faulted PCle card, note its location. To highlight the location of the
card in the controller picture, click on the card ID. To view details about the card, click its
information icon and then click Active Problems.
If adding a new PCIe card, identify the correct slot location as described in
■
Slots" on page
2. Shut down the controller using one of the power-off methods described in
"Powering Off the Controller" on page
3. Disconnect the AC power cords from the rear panel of the storage controller.
Because 3.3 VDC standby power is always present in the system, you must unplug
Caution -
the power cords before accessing any cold-serviceable components.
Extend the controller from the rack as described in
4.
Controller from the Rack" on page
Remove the top cover as described in
5.
6. Locate the PCIe card position in the storage controller.
100.
53.
Replacing or Adding a ZS5-4 PCIe Card
52.
"Extending the Storage
"Removing the Top Cover" on page
Servicing the ZS5-4 Controller
"ZS5-4 PCIe
54.
