Replacing or Adding a ZS5-4 PCIe Card

10. Ensure that the memory riser card connector is aligned with the slot.
11. Firmly push down on the metal bracket on top of the card, to seat the card within
the connector on the motherboard.
12. Replace the top cover on the chassis.
13. Return the controller to the normal rack position by pushing the release tabs on
the side of each rail while slowly pushing the storage controller into the rack.
14. Reconnect all cables to their original ports, referring to the labels previously
added as a guide. For cabling details, see the
Cabling
Reconnect the power cords to the power supplies.
15.
16. Verify that standby power is on, indicated by the Power/OK status indicator
flashing on the front panel about two minutes after the power cords are plugged
in.
Press and release the recessed Power button on the storage controller front
17.
panel.
Go to the Maintenance > Hardware screen of the BUI. Click the right-arrow icon
18.
for the controller and then click DIMM to verify that the status icon
for the newly installed memory riser card.
If a fault does not self-clear, see
19.
Replacing or Adding a ZS5-4 PCIe Card
Caution -
discharge, which can cause the component to fail. To avoid damage, wear an antistatic wrist
strap and use an antistatic mat when handling components.
Replacing or adding a PCIe card is a cold-swap procedure, and you must remove power
from the storage controller. If you are installing a newly released HBA, upgrade your system
software before installing the HBA as described in
All HBAs must be of the same type. Use the following procedure to replace or add a ZS5-4
PCle card.
72 Oracle ZFS Storage Appliance Customer Service Manual • December 2016
Guide.
This procedure requires that you handle components that are sensitive to static
Oracle ZFS Storage Appliance
"Repairing Active Problems" on page
"Upgrading the Software" on page
is green
39.
419.
