USB Host

7.8.1

Description

The
STM32MP135F-DK
use of the USB hub. The USB hub has a full power management for each USB port: no I/O is needed from the
STM32MP135FAF7.
7.8.2

USB Host interface

Table 6
describes the I/O configuration for the USB Host interface.
I/O
PD1
PH6
USB_PD1
USB_DM1
1. I2C5 not connected by default (R166 and R167 OFF).
Figure 6
shows the CN5 and CN6 USB Type-A connectors pinout.
Table 7
describes the CN5 and CN6 USB Host connectors pinout.
Pin
T1
T2
T3
T4
B1
B2
UM2993 - Rev 2
provides four USB Host ports (dual-USB Type-A sockets CN5 and CN6) through the
Table 6.
I/O configuration for the USB Host interface
PD1 used as I2C5_SCL shared between LCD and MIPI CSI-2
PH6 used as I2C5_SDA shared between LCD and MIPI CSI-2
USB1_P
USB1_N
Figure 6.
CN5 and CN6 USB Type-A connector pinout
Table 7.
CN5 and CN6 USB Host connectors pinout
Pin name
T1
T2
T3
T4
B1
B2
Configuration
®
(1)
®
(1)
Signal name
CN5
VBUS
USB1CN26_N
USB1CN26_P
GND
VBUS
USB1CN26_N
UM2993
USB Host
Function
VBUS
DM
DP
GND
VBUS
DM
page 14/42
