ST STM32MP135F-DK User Manual page 31

Ball
W13
AA15
Y15
Y17
AA16
Y16
AA19
AA20
Y19
W18
A20
C18
C19
A19
A18
B18
C17
B17
C16
B16
B15
C14
A16
A15
E14
D14
E13
B14
B13
C13
A13
C12
B11
A12
A10
B10
C11
D11
C10
A9
B8
UM2993 - Rev 2
Pin
PA14 PA14 (user button 1)
PI5-BOOT1 BOOT1
PI6-BOOT2 BOOT2
PI4-BOOT0 BOOT0
USB_DM1 USB_DM1
USB_DP1 USB_DP1
PA10 STM32G0_WAKE
PI7 LCD_DISP
PH4 uSD_DETECT
PH5 STLINK_SWO
PC9 SDMMC1_D1
PC8 SDMMC1_D0
PD2 SDMMC1_CMD
PC12 SDMMC1_CK
PC10 SDMMC1_D2
PC11 SDMMC1_D3
PG6 SDMMC2_CMD
PE3 SDMMC2_CK
PB4 SDMMC2_D3
PB14 SDMMC2_D0
PB15 SDMMC2_D1
PB3 SDMMC2_D2
PF0 WL_HOST_WAKE
PB9 I2C4_SDA
PH10 BT_PCM_SDO
PB13 BT_PCM_WS
PB10 BT_PCM_CK
PC6 LCD_HSYNC
PB5 BT_PCM_SDI
PC7 LCD_G6
PF3 LCD_G3
PH9 LCD_DE
PF1 LCD_B7
PH13 LCD_G2
PG7 LCD_R2
PG4 LCD_VSYNC
PB12 LCD_R3
PF2 LCD_B3
PE10 BT_HOST_WAKE
PE15 I2C4_SCL
PH14 LCD_B4
STM32MP135F-DK I/O assignment
Assignment
UM2993
page 31/42
