Figure 11
shows the pinout of the CN11 VBAT connector.
Table 20
describes the VBAT interface and pinout of connector CN11.
UM2993 - Rev 2
Figure 11.
Table 20.
Pin
1
2
CN11 VBAT connector pinout
CN11 VBAT connector pinout
Pin name
VBAT
GND
UM2993
VBAT connector
Function
VBAT supply.
Ground.
