Figure 9 shows the pinout of CSI connector CN1.
Table 14 describes the CSI interface and pinout of CSI connector CN1.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
UM2993 - Rev 2
Figure 9. CN1 CSI connector pinout
Table 14. CSI interface and CN1 connector pinout
STM32 pin
-
-
-
-
-
-
-
-
-
-
MCP_IO3
MCP_IO4
PD1
PH6
-
Signal name
GND
Negative data lane 1 from MIPI-CSI
DATA1_N
Positive data lane 1 from MIPI-CSI
DATA1_P
GND
Negative data lane 2 from MIPI-CSI
DATA2_N
Positive data lane 2 from MIPI-CSI
DATA2_P
GND
CKL_N Negative clock lane
CKL_P Positive clock lane
GND
CAM_ENABLE Camera shutdown
CAM_RESET
I2C5_SCL shared between USB and
I2C5_SCL
I2C5_SDA shared between USB and
I2C5_SDA
3V3_SW
UM2993
CSI-DCMI
Function
GND
receiver 1
receiver 1
GND
receiver 1
receiver 1
GND
GND
Camera reset
touch panel
touch panel
3V3
