Figure 5. Stm32Mp135F-Dk Pcb Layout: Bottom Side - ST STM32MP135F-DK User Manual

CSI connector
(CN1)
Ethernet 2
(CN15)
Ethernet 2 PHY
(U7)
Ethernet 1 PHY
(U13)
Ethernet 1
(CN4)
5 V power in
(CN12)
UM2993 - Rev 2
Figure 5. STM32MP135F-DK PCB layout: bottom side
STMIPID02
de-serializer
(U2)
STPMIC1
STM32MP135
(U19)
USB hub
(U33)
LCD backlight power supply
(U9)
USB Type-C
(U14)
USB Host
USB Host
(CN6)
(CN5)
UM2993
Hardware layout
Wi-Fi ® / BLE
(U1)
microSD™
card
(CN3)
STM32
ST-LINK
(U12)
DDR3L
(U17)
STM32G0
(U21)
®
DRP
(CN7)
