ST STM32MP135F-DK User Manual page 30

Ball
P3
R2
N3
R1
T2
T3
U2
R3
W1
V3
W2
V1
T4
Y1
AA2
Y2
Y3
W4
AA3
Y4
Y5
W5
AA4
V6
Y6
AA6
Y7
W6
AA7
W8
W9
Y8
Y9
U10
AA9
W10
Y10
AA10
AA13
Y13
Y12
UM2993 - Rev 2
Pin
PF7 ETH2_TXD0
PG11 ETH2_TXD1
PH6 I2C5_SDA
PG1 FDCAN2_TX
PE6 MCO2
PH0-OSC_IN HSE_IN
PH1-OSC_OUT HSE_OUT
PH3 SPI5_MOSI
PG3 FDCAN2_RX
PG2 ETH1_MDC
PG12 MCP_INT
PD7 MCO1
PA13 PA13 (user button 2)
PA11 ETH1_CLK
PB11 ETH1_TX_EN
PF14 STLINK_SWCLK
PA0 SAI1_SDB
PF13 DFSDM1_DATIN3
PA1 ETH1_RX_CLK
PA2 ETH1_MDIO
PA5 SAI1_SDA
PC0 USART1_TX
PF12 USB_PWR_CC1
PA7 USART1_CTS
PF11 SAI1_FSA
PA4 SAI1_SCKA
PC4 ETH1_RXD0
PC3 DFSDM1_CKOUT
PC5 ETH1_RXD1
PB0 USART1_RX
PA3 USB_PWR_CC2
PB1 TIM3_CH4
PC1 ETH1_CRS_DV
PA6 TAMP_BTN
PG13 ETH1_TXD0
PE5 TIM8_CH3
PG14 ETH1_TXD1
PC2 USART1_RTS
USB_DP2 USB_DP2
USB_DM2 USB_DM2
PF15 STLINK_SWDIO
STM32MP135F-DK I/O assignment
Assignment
UM2993
page 30/42
