Atlas Copco TPS Control User Manual page 41

TPS Control
Format label data
Parameter name
Control length
Number of STX
chars
Character code
STX1-STX4
Number of ETX
chars
Character code
ETX1-ETX4
Id1 Length
Id1 position
Counted from
Id2 Length
Id2 position
Counted from
Parameter name
Control length
Number of STX
chars
Character code
STX1-STX4
Number of ETX
chars
Character code
ETX1-ETX4
Id1 Length
Id1 position
Counted from
Id2 Length
Id2 position
Description
Defines the length of the barcode label.
Sets the number of prefix characters.
Only visible if Number of STX chars = 1-4.
Sets the number of postfix characters
Only visible if Number of ETX chars = 1-4.
Sets the number of characters used for the part of the
barcode defined as Id1
Position of first character for reporting string Id1 (ex-
tracted from the Barcode)
Id1 position to be counted from; either the head or the
tail of the barcode string
Sets the number of characters used for the part of the
barcode defined as Id2
Position of first character for reporting string Id2 (ex-
tracted from the Barcode)
Id2 position to be counted from; either the head or the
tail of the barcode string
Description
Defines the length of the barcode label.
Sets the number of prefix characters.
Only visible if Number of STX chars = 1-4.
Sets the number of postfix characters
Only visible if Number of ETX chars = 1-4.
Sets the number of characters used for the part of the
barcode defined as Id1
Position of first character for reporting string Id1 (ex-
tracted from the Barcode)
Id1 position to be counted from; either the head or the
tail of the barcode string
Sets the number of characters used for the part of the
barcode defined as Id2
Position of first character for reporting string Id2 (ex-
tracted from the Barcode)
© Atlas Copco Industrial Technique AB - 9836 5819 01
EN User guide
Range/Values
Variable, 1-53
Default: 8
0-4
Default: 0
0-4
Default: 2
0-32
Default: 0
1-128
Default: 1
head, tail
Default: head
0-32
Default: 0
1-128
Default: 1
head, tail
Default: head
Range/Values
Variable, 1-53
Default: 8
0-4
Default: 0
0-4
Default: 2
0-32
Default: 0
1-128
Default: 1
head, tail
Default: head
0-32
Default: 0
1-128
Default: 1
41
