TPS Control
Parameter name
Out OK
Out NOK
Out complete OK
Out complete NOK
Out Pset bit 1
Out Pset bit 2
Out Pset bit 4
Out Pset bit 8
Out Pset bit 16
Out Pset bit 32
Out Pset bit 64
Out Pset bit 128
Out I/O Rework
Sequence
Parameter name
Label
Start signal
Description
Output for the OK signal for individual tightening oper-
ations.
Output for the NOK signal for individual tightening op-
erations
Output for a job with all OK signals, that is, all posi-
tions successfully processed.
Output for a job with all NOK signals, which indicate
that the job is cancelled.
Bit 1 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
Bit 2 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
Bit 3 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
Bit 4 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
Bit 5 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
Bit 6 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
Bit 7 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
Bit 8 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
Output for an additional signal, which interacts with the
OK output for individual tightening, but indicates that
there was a preceding skip/forward operation in that
job.
Description
Defines how a job should be started when the TPS re-
ceives label information from a barcode scanner
Selects between
■
Edge
To start a job, it is necessary to change from low
to high input signal
■
Level
Job always starts, when the input signal is high
■
Continuous
To start a job requires a rising edge. Also, the start
signal must be available during the entire opera-
tion (otherwise the operation will end)
© Atlas Copco Industrial Technique AB - 9836 5819 01
EN User guide
Range/Values
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
---, OUT-1...OUT-6
Default: ---
Range/Values
allow start, change job, start job
Default: allow start
Edge, Level, Continuous
Default: Edge
