Parameter name
Loosening / rework
Force ext. Job se-
lection
Jobselect bit 1
Jobselect bit 2
Jobselect bit 4
Jobselect bit 8
Jobselect bit 16
Jobselect bit 32
Output configuration
Parameter name
Output ready
Output in job
Out clamp 1
Out clamp 2
Out tool enable
Out tool disable
Out in position
36
Description
Activates a Loosen and rework mode (repair mode)
which enables you to go back to already-processed
positions to unscrew, adjust or repair previous opera-
tions.
The input signal can force a change of the selected
job method.
If the input is inactive, the job will be selected with the
method given in the system parameter Job selection.
If the input is active, external inputs will select the job,
regardless of the setting of system parameter job se-
lection.
Bit 1 of a Job Select value (0-5 bits possible)
Bit 2 of a Job Select value (0-5 bits possible)
Bit 3 of a Job Select value (0-5 bits possible)
Bit 4 of a Job Select value (0-5 bits possible)
Bit 5 of a Job Select value (0-5 bits possible)
Bit 6 of a Job Select value (0-5 bits possible)
Description
Is activated if the TPS can process a start signal.
Is set to 1 when a job is being processed.
If the parameter Out clamp 2 is not set, this output ac-
tuates a spring valve. If the Out clamp 2 signal is set,
the clamp 1 output will send the pulse to engage
clamping.
If this output is set, both the clamp 1 and clamp 2 out-
puts will be used to actuate a pulse valve. In this case,
clamp 1 sends the Engage Clamping signal and clamp
2 sends the Disengage Clamping signal. The pulse
duration can be configured via the Clamping Pulse
Duration item in the Process menu.
Enables the tool controller as soon as the position is
lost and, if applicable, defined additional query condi-
tions are met.
Disables the tool controller as soon as the position is
reached and, if applicable, defined additional query
conditions are met.
Changes to active as soon as a specified position has
been reached.
