Parameter name
SSI resolution
SSI factor
SSI Divider
Air option parameter
This menu is only visible if the parameter tool model is set to Air tool..
Parameter name
Pneumatic Pset 1-4
T0
Pneumatic Pset 1-4
T1
Pneumatic Pset 1-4
T2
Barcode input
Parameter name
Format label data
Define new code
40
Description
Defines the SSI resolution in bits for the SSI sensor.
TPS uses a 13-bit value to calculate the resolution; us-
ing a 13-bit encoder gives a maximum encoder value
of 8191.
If you are using an SSI sensor with a resolution other
than 13, you will get a lower or higher maximum value.
The aim is to come as close as possible to the value
8191.
For lower values than 13 bits:
SSI factor x Max value = Should return a value as
close as possible to 8191.
SSI Divider = 1
For higher values than 13 bits:
SSI factor = 1
Max value / SSI Divider = Should return a value as
close as possible to 8191.
See SSI resolution for explanation
See SSI resolution for explanation
Description
Sets the minimum time period that the tool must run
before the tightening operation is evaluated. If the tool
runs for less time period 2 times in a row, the TPS re-
ports the operation as NOK.
Depending on the time needed to run down and
tighten the screw, you may need to adjust the parame-
ter settings regarding time intervals for air tools.
Sets the minimum time period for which the tool must
run to get an OK on the tightening operation.
Depending on the time needed to run down and
tighten the screw, you may need to adjust the parame-
ter settings regarding time intervals for air tools.
Sets the maximum time period for which the tool can
run to get an OK on the tightening operation.
Depending on the time needed to run down and
tighten the screw, you may need to adjust the parame-
ter settings regarding time intervals for air tools.
Description
Opens a submenu.
Opens a submenu.
© Atlas Copco Industrial Technique AB - 9836 5819 01
EN TPS Control
Range/Values
8-24
Default: 13
1-99
Default: 1
1, 2, 4, 8, 16, 32, 64, 128
Default: 1
Range/Values
0.00-0.40 seconds
Default: 0.1
0.0-99.9 seconds
Default: 0.5
0.0-99.9 seconds
Default: 2.0
Range/Values
