User guide
Parameter name
C2:data bits
C2:parity
Display set up
Parameter name
Display contrast
Screen saver (min)
RGB portion Red
RGB portion Green
RGB portion Blue
34
Description
Allows you to set the data byte length for the barcode
reader interface
Enables the definition of the parity method for the bar-
code reader interface
Description
Adapts the display contrast to the surroundings
Sets the time limit for the idle period before the
screensaver is activated.
Sets a fixed percentage value to specify the amount of
red, green and blue colour in the display backlight. For
example, for a completely white backlight, set
Red=100%, Green=100%, and Blue=100%. For a
pure red backlight, set R=100%, G=0%, and B=0%.
See RGB portion Red
See RGB portion Red
© Atlas Copco Industrial Technique AB - 9836 5819 01
EN TPS Control
Range/Values
7, 8
Default: 8
None, even, odd
Default: None
Range/Values
30-63
Default: 48
Off, 1-15 minutes
Default: 6
25%
37%
50%
62%
100%
Default: 50%
25%
37%
50%
62%
100%
Default: 50%
25%
37%
50%
62%
100%
Default: 50%
