Alinx AX7035 User Manual page 35

Figure 17-1: Expansion header J9 schematic
Figure 17-2: Expansion header J9on the FPGABoard
J9 Expansion Header Pin Assignment
J9 Pin Number
1
3
5
7
9
11
13
15
17
19
35 / 42
ARTIX-7 FPGA Development Board AX7035 User Manual
FPGA Pin
GND
D16
F14
E14
D15
B13
A14
C15
A16
B16
Amazon Store:
Sales Email:
J9 Pin Number
2
4
6
8
10
12
14
16
18
20
https://www.amazon.com./alinx
rachel.zhou@aithtech.com
FPGA Pin
+5V
E16
F13
E13
D14
C13
A13
C14
A15
B15
