Part 16: Temperature Sensor - Alinx AX7035 User Manual

DIG5
DIG6
DIG7
SEL0
SEL1
SEL2
SEL3
SEL4
SEL5

Part 16: Temperature Sensor

A high-precision, low-power, digital temperature sensor chip is mounted on
the AX7035 FPGA development board, and the model is LM75 of ON
Semiconductor. The temperature accuracy of the LM75 chip is 0.5 degrees.
The sensor and FPGA are directly connected to the I2C digital interface. The
FPGA reads the temperature near the current FPGA development board
through the I2C interface. Figure 16-1 below shows the design of the LM75
sensor chip.
33 / 42
ARTIX-7 FPGA Development Board AX7035 User Manual
K6
K3
H4
M2
N4
L5
L4
M16
M17
Figure 16-1: LM75 Sensor Schematic
Amazon Store:
Sales Email:
Corresponding segment F
Corresponding segment G
Corresponding point DP
The first digital tube from the right
The second digital tube from the right
The third digital tube from the right
The fourth digital tube from the right
The fifth digital tube from the right
The sixth digital tube from the right
