7.
Port Settings should be set to Bits per second = 9600, Data bits = 8, Parity = None, Stop bits = 1, and
Flow control = None, as Figure 5 illustrates:
Figure 5
8.
Select OK to connect to your router.
9.
The Hyperterminal window should be blank with a flashing cursor in the top left corner. Turn on the router.
10.The router Main Menu should appear within a few seconds, and look that the following Figure 6:
Figure 6
10. If not, press the Control and L keys simultaneously to refresh the screen.
Step IV: Confirm your router's configuration
1.
Once you are connected to the menu interface of your router (via either telnet or a console connection,
Steps II or III) keep in mind that pressing the Return/Enter key takes you into a page, pressing the Escape
key takes you out, and pressing the tab key acts as a toggle on router settings. You also must press
Return/Enter to save any new setting you enter.
2.
Easy Setup will show you all the parameters that have been configured for your router's Internet access. If
your router was pre-configured, we advise you do not make any changes to your router's configuration
before reviewing the information provided to you by your service provider.
Troubleshooting A-9
