15-2 User's Reference Guide
Tunneling is a process of creating a private path between a remote user or private network and another private
network over some intermediate network, such as the IP-based Internet. A VPN allows remote offices or
employees access to your internal business LAN through means of encryption allowing the use of the public
Internet to look "virtually" like a private secure network. When two networks communicate with each other
through a network based on the Internet Protocol, they are said to be tunneling through the IP network.
Unlike the phone company, private and public computer networks can use more than one protocol to carry your
information over the wires. Three such protocols are in common use for tunnelling, Point-to-Point Tunnelling
Protocol (PPTP), Ascend Tunnel Management Protocol (ATMP), and IP Security (IPsec). The Netopia Router can
use any of them.
Point-to-Point Tunneling Protocol (PPTP) is an extension of Point-to-Point Protocol (PPP) and uses a client
and server model. Netopia's PPTP implementation is compatible with Microsoft's and can function as
either the client (PAC) or the server (PNS). As a client, a Netopia R6000 Series Router can provide all users
on a LAN with secure access over the Internet to the resources of another LAN by setting up a tunnel with
a Windows NT server running Remote Access Services (RAS) or with another Netopia Router. As a server, a
Netopia R6000 Series Router can provide remote users a secure connection to the resources of the LAN
over a dial-up, cable, DSL, or any other type of Internet access. Because PPTP can create a VPN tunnel
using the Dial-Up Networking (DUN) (see
Windows 95, 98, or NT, no additional client software is required.
Ascend Tunnel Management Protocol (ATMP) is the protocol that is implemented in many Ascend routers.
ATMP is a simple protocol for connecting nodes and/or networks together over the Internet via a tunnel.
ATMP encapsulates IP or other user data without PPP headers within General Routing Encapsulation (GRE)
protocol over IP. ATMP is more efficient than PPTP for network-to-network tunnels.
IP Security (IPsec) is a set of protocols that supports secure exchange of IP packets at the IP layer. IPsec
is widely used to implement Virtual Private Networks. DES stands for Data Encryption Standard, a popular
symmetric-key encryption method. DES uses a 56-bit key. The optional VPN Accelerator (TER/VPN1)
increases the level of encryption by offering 3DES (Triple-DES) encryption for VPN tunnel Connection
Transit Internetwork
Virtual Private Network
Logical
Equivalent
"Dial-Up Networking for VPN" on page 15-15) utility built into
