Advanced Ip Profile Options - Netopia R6100 Reference Manual

The following IP Profile Options screen is displayed for an IPsec Connection Profile.
SPI (Security Parameters Index):
Remote Tunnel Endpoint Address:
Remote Members Network:
Remote Members Mask:
Address Translation Enabled:
NAT Map List...
NAT Server List...
PAT IP Address:
Filter Set...
Remove Filter Set
Advanced IP Profile Options...
You must specify an SPI (Security Parameters Index), which is the ESP receive side SPI and the default
SPI for ESP transmit, AH receive, and AH transmit. It must be unique relative to any other configuration
profile "ESP Receive SPIs." (See
You must specify a Remote Tunnel Endpoint Address. Specify the IP address of your tunnel partner, the
endpoint of the tunnel. The Remote Tunnel Endpoint Address may be 0.0.0.0, which implies that the IPsec
tunnel will not be established until packets are received on the SPI specified. At that time the tunnel will be
bound to the Remote Tunnel Endpoint until traffic from the remote gateway ceases for a timeout period.
You must specify a Remote Members Network address. This specifies the subnet of the remote IPsec
tunnel and will be used with the Remote Members Mask to determine and set the route.
You must specify a Remote Members Mask. This is the subnet mask of the remote subnet to which the
IPsec tunnel will route.
You can specify Address Translation Enabled. For more information see
Address Translation (MultiNAT)."
three fields:
NAT Map List
NAT Server List
PAT IP Address
(Note: Since there is no protocol to derive this address, 0.0.0.0 is not permitted.)
Map Lists, Server Lists, and PAT addresses are described in detail in
Address Translation (MultiNAT)."
You can specify a Filter Set. See the sections on filter sets in the accompanying User's Reference Guide on
your Netopia CD.
IP Profile Options
COMMIT
"Advanced IP Profile Options" on page
If Address Translation Enabled is set to Yes, you can specify the following
Virtual Private Networks (VPN) 15-11
