Configuring the Preloaded Applications
Parameter
Input 1 Configuration
Input 2 Configuration
Input 3 Configuration
Input 4 Configuration
Input 5 Configuration
Input 6 Configuration
Input 7 Configuration
Input 8 Configuration
Input 6 Signal Type
Input 7 Signal Type
Input 8 Signal Type
Temperature Sensors Type
Temperature Sensors Units
CO Range Maximum Value
2
CO Range Minimum Value
2
54
Unconfig – Hardware Input is not used.
SpaceTemp – Space temperature sensor.
FanStatus – Digital fan status input.
OccDetect – Motion detection sensor.
AuxiliaryContact – Auxiliary contact.
EconEnable – Economizer enable input.
Window – Window contact.
Unconfig – Hardware Input is not used.
SpOffset – Setpoint offset potentiometer.
FanStatus – Digital fan status input.
OccDetect – Motion detection sensor.
AuxiliaryContact – Auxiliary contact.
EconEnable – Economizer enable input.
Window – Window contact.
Unconfig – Hardware Input is not used.
ReturnTemp – Return temperature sensor.
FanStatus – Digital fan status input.
OccDetect – Motion detection sensor.
AuxiliaryContact – Auxiliary contact.
EconEnable – Economizer enable input.
Window – Window contact.
Unconfig – Hardware Input is not used.
DischTemp – Discharge temperature sensor.
FanStatus – Digital fan status input.
OccDetect – Motion detection sensor.
AuxiliaryContact – Auxiliary contact.
EconEnable – Economizer enable input.
Window – Window contact.
Unconfig – Hardware Input is not used.
OutdoorTemp – Outdoor temperature sensor.
FanStatus – Digital fan status input.
OccDetect – Motion detection sensor.
AuxiliaryContact – Auxiliary contact.
EconEnable – Economizer enable input.
Window – Window contact.
Unconfig – Hardware Input is not used.
FanCurrent – Analog fan current input.
ReturnHumid – Return humidity sensor.
DischHimid – Discharge humidity sensor.
SpaceHumid – Space humidity sensor.
OutdoorHumid – Outdoor humidity sensor.
Unconfig – Hardware Input is not used.
SpaceCO2 – Space CO sensor.
2
ReturnHumid – Return humidity sensor.
DischHimid – Discharge humidity sensor.
SpaceHumid – Space humidity sensor.
OutdoorHumid – Outdoor humidity sensor.
Unconfig – Hardware Input is not used.
ReturnCO2 – Return CO sensor.
2
ReturnHumid – Return humidity sensor.
DischHimid – Discharge humidity sensor.
SpaceHumid – Space humidity sensor.
OutdoorHumid – Outdoor humidity sensor.
0-10V
2-10V
4-20mA
0-5V
10K Type 2
10K Type 3
PT1000
NI1000@0C
NI1000@22C
Choose between Degrees Celcius or Fahrenheit.
Enter the maximum scaling of UI7 or UI8 when configured for SpaceCO2 or ReturnCO2.
The range of the input can be configured using UI7 Signal Type or UI8 Signal Type.
Enter the minimum scaling of UI7 or UI8 when configured for SpaceCO2 or ReturnCO2.
The range of the input can be configured using UI7 Signal Type or UI8 Signal Type.
Description
ECY-303 Preloaded Applications
