DO2: DO2 (DO2)

This output is used to control the cooling stage 1 of the unit.
ID
DO2

DO3: DO3 (DO3)

This output is used to control the various possible equipements of the unit (Cooling stage, heating
stage, economizer, etc) based on the configuration of CoolHeatConfig (MSV32), RevValveConfig(
MSV33), DampersConfig(MSV35), HumidifierConfig(MSV36). Once all the configurations have
been made, the variable Output3ConfigSt(MSV38) will display what needs to be wired to this output.
See section IO assignment for more details.
ID
DO3

DO4: DO4 (DO4)

This output is used to control the various possible equipements of the unit (Cooling stage, heating
stage, economizer, etc) based on the configuration of CoolHeatConfig (MSV32), RevValveConfig(
MSV33), DampersConfig(MSV35), HumidifierConfig(MSV36). Once all the configurations have
been made, the variable Output4ConfigSt(MSV39) will display what needs to be wired to this output.
See section IO assignment for more details.
ID
DO4

DO5: DO5 (DO5)

This output is used to control the various possible equipements of the unit (Cooling stage, heating
stage, economizer, etc) based on the configuration of CoolHeatConfig (MSV32), RevValveConfig(
MSV33), DampersConfig(MSV35), HumidifierConfig(MSV36). Once all the configurations have
been made, the variable Output5ConfigSt(MSV40) will display what needs to be wired to this output.
See section IO assignment for more details.
ID
DO5

AO6: AO6 (AO6)

This output is used to control the various possible equipements of the unit (Cooling stage, heating
stage, economizer, etc) based on the configuration of CoolHeatConfig (MSV32), RevValveConfig(
MSV33), DampersConfig(MSV35), HumidifierConfig(MSV36). Once all the configurations have
been made, the variable Output6ConfigSt(MSV41) will display what needs to be wired to this output.
See section IO assignment for more details.
ID
AO6

AO7: AO7 (AO7)

This output is used to control the various possible equipements of the unit (Cooling stage, heating
stage, economizer, etc) based on the configuration of CoolHeatConfig (MSV32), RevValveConfig(
MSV33), DampersConfig(MSV35), HumidifierConfig(MSV36). Once all the configurations have
ECY-303 Preloaded Applications
Units
On/Off
Units
On/Off
Units
On/Off
Units
On/Off
Units
Percent (%)
Valid Range
On to Off
Valid Range
On to Off
Valid Range
On to Off
Valid Range
On to Off
Valid Range
0 to 100%
Variables
Default Value
Off
Default Value
Off
Default Value
Off
Default Value
Off
Default Value
0%
15
