Ui1Config (Msv24); Ui2Config (Msv25); Ui3Config (Msv26); Ui4Config (Msv27) - Distech Controls ECLYPSE ECY-303 User Manual

Variables
ID
Multi State Value 22

UI1Config (MSV24)

This variable is used to configure the source of Hardware Input 1.
ID
Multi State Value 24

UI2Config (MSV25)

This variable is used to configure the source of Hardware Input 2.
ID
Multi State Value 25

UI3Config (MSV26)

This variable is used to configure the source of Hardware Input 3.
ID
Multi State Value 26

UI4Config (MSV27)

This variable is used to configure the source of Hardware Input 4.
36
Enumeration
1 = 0-10V: The range is from 0 to 10 V
2 = 2-10V: The range is from 2 to 10 V
3 = 4-20mA: The range is from 4 to 20 mA
4 = 0-5V : The range is from 0 to 5 V
Enumeration
1 = Unconfig : Hardware Input is not used
2 = SpaceTemp : The input is used to connect a space temperature
sensor
3 = FanStatus : The input is used to connect a digital fan status input
4 = OccDetect : The input is used to connect a motion detection sensor
5 = AuxiliaryContact: The input is used to connect an auxiliary contact
6 = EconEnable : The input is used to connect an economizer enable
input.
7 = Window : The input is used to connect a window contact
Enumeration
1 = Unconfig : Hardware Input is not used
2 = SpOffset : The input is used to connect a setpoint offset
potentiometer
3 = FanStatus : The input is used to connect a digital fan status input
4 = OccDetect : The input is used to connect a motion detection sensor
5 = AuxiliaryContact: The input is used to connect an auxiliary contact
6 = EconEnable : The input is used to connect an economizer enable
input.
7 = Window : The input is used to connect a window contact
Enumeration
1 = Unconfig : Hardware Input is not used
2 = ReturnTemp : The input is used to connect a return temperature
sensor
3 = FanStatus : The input is used to connect a digital fan status input
4 = OccDetect : The input is used to connect a motion detection sensor
5 = AuxiliaryContact: The input is used to connect an auxiliary contact
6 = EconEnable : The input is used to connect an economizer enable
input.
7 = Window : The input is used to connect a window contact
Default Value
0-10V
Default Value
SpaceTemp
Default Value
SpOffset
Default Value
ReturnTemp
ECY-303 Preloaded Applications
