ECB-VAVS Preloaded Applications
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECB-VAVS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Distech Controls ECB-VAVS

Summary of Contents for Distech Controls ECB-VAVS

  • Page 1 ECB-VAVS Preloaded Applications User Guide...
  • Page 2 ©, Distech Controls Inc. 2010. All rights reserved. While all efforts have been made to verify the accuracy of information in this manual, Distech Controls is not responsible for damages or claims arising from the use of this manual. Persons using this man-...

  • Page 3: Table Of Contents

    Table of Contents ABLE OF ONTENTS Introduction............................... 5 Introduction to the ECB-VAVS Preloaded Applications ................ 5 Applications Comparison Chart ........................ 5 About This User Guide .......................... 6 Purpose of the User Guide ...................... 7 Intended Audience ........................ 7 Conventions Used in this Document.....................  7 Acronyms and Abbreviations Used in this Document ..............
  • Page 4 Table of Contents Setting up the Parameters and Calibrating the Sensor ................ 43 How to Enter the General Configuration Submenu.............. 44 How to Set the BACnet MS/TP Communication Network Parameters ........ 45 How to Calibrate the Sensor and Adjust the Screen Contrast ............  46 How to Exit the Submenu ......................

  • Page 5: Introduction

    Introduction Introduction In the first chapter, the ECB-VAVS preloaded applications are introduced and an overview of this user guide is provided. Introduction to the ECB-VAVS Preloaded Applications Distech Controls’ ECB-VAVS controllers come preloaded with code containing standard VAV applica- tions. This code was created using EC- gfx Program, a Graphical Programming Interface (GPI) tool that enables visual assembly of building blocks and the design of custom programs that control Building Automation Systems.

  • Page 6: Applications Comparison Chart

    10K Type II 10K Type II 10kK Type III 10kK Type III 10K Type II Sensor Type PT1000 PT1000 10kK Type III NI1000 @ 0C NI1000 @ 0C NI1000 @ 22C NI1000 @ 22C Table 1: Available configurations ECB-VAVS Preloaded Applications...

  • Page 7: About This User Guide

    Applications or an Allure EC-Smart-Vue sen- sor. However, this guide is not designed to instruct the user on how to use an ECB-VAVS controller. For information on this controller series, refer to its datasheet and to the EC- gfx Program user guide, both of which are available on SmartSource.

  • Page 8: Sequence Of Operation

    Sequence of Operation Sequence of Operation This chapter presents various aspects of the sequence of operation of an ECB-VAVS controller. Top- ics covered include occupancy control, temperature setpoints, HVAC modes, airflow control, CO sensing, heat control, and fan control. Occupancy Control, Temperature Setpoints, and HVAC...

  • Page 9: Space Temperature Setpoints

    For instructions on how to adjust the setpoints using the dc gfx Applications interface, see Configuring the Space Temperature Setpoints. For screen-by-screen steps on how to adjust the setpoints using an Allure EC-Smart-Vue sensor, see Adjusting the Setpoints and Display Units. ECB-VAVS Preloaded Applications...

  • Page 10: Hvac Modes

    CommFailDelay(AV54), HVACModeCmd falls back to Auto. HVACModeCmd (MV2) The supported modes are: (1)-AUTO, (2)-HEAT, (3)-MRNG_WRMUP, (4)-COOL, (5)- NIGHT_PURGE, (6)-PRE_COOL and (7)-OFF. HVACModeStatus (MV15) is controlled by HVACModeCmd. When HVACModeCmd is HVACModeStatus (MV15) set to Auto, HVACModeStatus reflects the room’s actual terminal load. ECB-VAVS Preloaded Applications...

  • Page 11: Airflow Control And Calibration

    When the VVTMode (BV12) option is selected, ActFlowSP is converted into a percentage, which con- trols the damper without using a flow reading. The dual maximum option, DualMaximum (BV19), is available for the ECB-VAVS model. When in heating mode, ActFlowSP is controlled as follows (see Figure 1): The first 50 percent of the heating load adjusts the DischAirSP (AV12) between 55°F and MaxDischAirSP (AV56).

  • Page 12: Airflow Calibration

    Calib (AV33). The K-factor will automatically adjust to the proper value. For instructions on how to perform VAV airflow balancing, see Air Flow Tab (VAV Balancing). For screen-by-screen steps on how to perform VAV airflow balancing using an Allure EC-Smart-Vue sensor, see Performing VAV Airflow Balancing. ECB-VAVS Preloaded Applications...

  • Page 13: Co 2 Sensor

    If CO2Load is 65% then AirFlowSetpoint is equal to the following: £ (((MaxFlowSp - MinFlowSp) x 0.65) + MinFlowSp) The AirFlow setpoint will be the maximum value between the air flow setpoint based on the space temperature and the CO flow setpoint. ECB-VAVS Preloaded Applications...

  • Page 14: Co 2 Elevation Input

    500ft (152m) above sea level. The Elevation input of the corresponding ComSensor block in EC- gfx- Program must be set to the current location’s elevation to obtain the most accurate readings. ECB-VAVS Preloaded Applications...

  • Page 15: Heat Control And Output Wiring

    Heating output is rescaled based on the percentage of shedding required. Example: Heating demand = 75% Shedding = 20% Max heating = 100% - 20% (shedding) = 80% Output = 75% (heating demand) x 80% (max heating) = 60% (Scaled output based on required shed- ding) ECB-VAVS Preloaded Applications...

  • Page 16: Output Wiring

    Applications interface, see Configuring the Preloaded Applications. For screen-by-screen steps on how to configure a controller’s outputs using an Allure EC-Smart-Vue sensor, see Setting up Outputs. ECB-VAVS Preloaded Applications...

  • Page 17: Vav Performance Assessment Control Charts (Vpacc)

    Sequence of Operation VAV Performance Assessment Control Charts (VPACC) The ECB-VAVS VPACC feature, which is embedded into the ECB-VAVScontrol sequences, provides a means of automatically detecting when the VAV is operating outside of its design parameters. In a traditional sequence of operations, alarms are triggered when the value of a point stays outside the alarm limit for a defined period of time.

  • Page 18: Vpacc Parameters

    AV93 DischTempPosErr VPACC Positive Discharge Temperature CUSUM (Δ°F) (Δ°K) £ AV94 DischTempNegErr VPACC Negative Discharge Temperature CUSUM (Δ°F) (Δ°K) £ MSV40 VPACCStatus VPACC Status Reporting: £ – Normal – LowSpaceTemp or HighSpaceTemp – LowDischTemp or HighDischTemp – UnstableAirFlow or LowAirFlow or HighAirFlow ECB-VAVS Preloaded Applications...

  • Page 19: Receiving Network Values

    CommFailDelay (AV54) is expired and given that the object was controlled at pri- ority 14. In the case where CommFailDelay not required, write selected points from the network at a priority other than 14. ECB-VAVS Preloaded Applications...

  • Page 20: Using The Dc Gfx Applications

    EC-BOS, refer to the Productivity Enhancing Tools User Guide . To access the preloaded applications of an ECB-VAVS controller, it must first be created in the Bcp- BacnetNetwork driver of the configured station and then matched with an existing device in the BAC- net Network.
  • Page 21 To add multiple copies of the same device, right-click the device just added, click Copy, and then right-click the BcpBacnetNetwork driver and click Paste Special. 3. Double-click the BcpBacnetNetwork driver. The Bcp Bacnet Device Manager appears in the View pane. ECB-VAVS Preloaded Applications...
  • Page 22 5. Select the discovered device that is to be matched with the one just added to the database. Click Match. The Match window appears. 6. Click OK. The device in the database is matched with the one in the discovered network. After matching is done, the device ID must be set. ECB-VAVS Preloaded Applications...
  • Page 23 8. Set the device ID according to the overall network planning. The device ID must be unique to a de- vice in the entire BACnet network internetwork. The valid range is from 0 to 4194302. Click OK. 9. Click OK again when the Change Device ID window appears. ECB-VAVS Preloaded Applications...
  • Page 24 Using the dc gfxApplications 10. In the Nav tree, double-click the device that was just added and matched. An overview of the VAV system in place appears in the View pane (shown below). ECB-VAVS Preloaded Applications...

  • Page 25: Configuring The Vav With Ec-Net 4

    Unoccupied mode. If the temperature passes these limits, the system reacts to bring Unoccupied the temperature back within these limits. In Unoccupied mode, the space temperature is usually allowed a larger amount of variance than in Occupied mode, thereby lowering operating costs. ECB-VAVS Preloaded Applications...

  • Page 26: Configuring The System Parameters

    Allure EC-Smart-Vue except after a password is entered. To learn how to perform various functions using the Allure EC-Smart-Vue’s basic and advanced menus, see Allure EC-Smart-Vue Screen-by-Screen Guide. Resulting Terminal Load Displays the terminal load on the unit. ECB-VAVS Preloaded Applications...

  • Page 27: Configuring The Flow Setpoints

    To initialize the damper, click the Edit button. The status will change from Normal to Initializing during the initialization process. The actuator mechanical stops should be moved only to limit damper movement from going under 0% or over 100%. ECB-VAVS Preloaded Applications...

  • Page 28: Configuring The Preloaded Applications

    To access the Configuration Assistant page: 1. In the Nav sidebar, right click the VAV you wish to configure and click Launch Wizard. Figure 10: Launching Wizard from the Nav Sidebar The Configuration Assistant page appears. Figure 11: Configuration Assistant Page in EC-gfxProgram ECB-VAVS Preloaded Applications...

  • Page 29: Overview Tab

    Figure 12: General Settings Overview Hardware Configuration Tab The Hardware Configuration tab includes Inputs, Outputs, Box, and Room Sensors configuration. A brief description of each type of configuration parameter is outlined below. Figure 13: Hardware Configuration Tab ECB-VAVS Preloaded Applications...
  • Page 30 Smart-Comfort offset setpoint range (any value between -10.0 and 10.0). Space Temperature Calibration Set the space temperature calibration offset. Offset Discharge Temperature Calibration Set the discharge temperature calibration offset. MaxRangeCO2 Set the maximum range for CO input. ECB-VAVS Preloaded Applications...
  • Page 31 Set the heat 2 type valve to normally open TRUE or normally open FALSE. Configuring the VAV Box The Box Configuration subsection allows for configuration of the VAV box. The table below gives a brief description of each type of configuration parameter. Figure 15: Box Configuration Subsection ECB-VAVS Preloaded Applications...
  • Page 32 Elevation greater than 500ft (152m) above sea level. By default, the sensor is factory calibrated to sea level. EC-Smart-Comfort/Air Sleep Time Enter the amount of time before the sensor goes into standby mode. ECB-VAVS Preloaded Applications...

  • Page 33: Hvac Control Tab

    In addition, if a motion sensor is present, the bypass mode override time represents how long the controller remains in occupied mode (no room occupancy is detected) before returning the controller to standby mode. Resulting Terminal Load Displays the resulting terminal load on the unit. ECB-VAVS Preloaded Applications...
  • Page 34 Set the delay in seconds in case of communication failure (120 seconds or more is Communication Failure Delay allowed). Pulse Width Modulation Period Set the triac pulse width modulation period. This is relevant to the heat type output code (Triac) when it is set to PWM Triac. ECB-VAVS Preloaded Applications...

  • Page 35: Air Flow Tab (Vav Balancing)

    The Air Flow tab allows a user to configure a damper box, calibrate a VAV box, and configure flow set- points. A brief description of each type of configuration parameter is outlined below. Figure 22: Air Flow Tab ECB-VAVS Preloaded Applications...
  • Page 36 Normal to Initializing during the initialization process. VVT Mode Determine whether the VAV box is using flow input or not. The actuator mechanical stops should be moved only to limit damper movement from going under 0% or over 100%. ECB-VAVS Preloaded Applications...
  • Page 37 4. Release the flow setpoint override by clicking the Edit button beside Flow Setpoint on the EC-Net 4 configuration PX page. Alternatively, return the Balancing Override setting to Normal Operation. At this point, the VAV controller is balanced. The adjusted K-Factor can be included in the balancing report. ECB-VAVS Preloaded Applications...

  • Page 38: Output Assignment

    1. Applicable to a parallel fan powered VAV Output Assignment The Output Assignment tab indicates which physical outputs are assigned to the configured outputs based on the Outputs Configuration in the Hardware Configuration tab. This facilitates output wiring. Figure 26: Outputs Assignment Subsection ECB-VAVS Preloaded Applications...

  • Page 39: Saving To Multiple Devices

    Figure 27: Configuration Assistant Synchronization window You must select the other devices you wish to save the current configuration to, as well as selecting which parameters you wish saved to those controllers. Click next to advance and complete the process. ECB-VAVS Preloaded Applications...

  • Page 40: Setting Up Trends

    To enable these two trends, refer to the following procedure: 1. In the Nav tree of EC-Net Pro, expand the Services folder of the configured station. 2. Double-click HistoryService. Figure 28: Double-clicking HistoryService The History Extension Manager appears in the View pane. Figure 29: History Extension Manager ECB-VAVS Preloaded Applications...
  • Page 41 Graphs of the collected data can be viewed in the Trends page of the dc gfx Applications interface. This page can easily be accessed from the VAV navigation menu located at the bottom of the dc gfx Applications interface. Figure 31: Trends Page ECB-VAVS Preloaded Applications...

  • Page 42: Allure Ec-Smart-Vue Screen-By-Screen Guide

    The heating setpoint starts blinking. 4. Use the arrow keys to increase or decrease the heating setpoint. °F Screen timeout: 3 sec 5. Press the Menu button to submit the new heating setpoint. °F Screen timeout: 3 sec ECB-VAVS Preloaded Applications...

  • Page 43: How To Put A Controller Into Bypass Mode

    Screen timeout: 3 sec 3. Press the Menu button. Screen timeout: 3 sec The controller goes into bypass mode. When in bypass mode, the Allure EC-Smart-Vue screen dis- plays the current time and also the remaining bypass time. ECB-VAVS Preloaded Applications...

  • Page 44: Setting Up The Parameters And Calibrating The Sensor

    Upon submitting the correct password, the advanced menu is displayed. 4. Press the Menu button several times until GEN CFG appears on the display. Press several times 5. Press either of the arrow keys to enter the General Configuration submenu. ECB-VAVS Preloaded Applications...

  • Page 45: How To Set The Bacnet Ms/Tp Communication Network Parameters

    3. Press the Menu button once to move onto the next parameter. Screen timeout: 30 s The Baud Rate parameter appears on the display. 4. Use the arrow keys to set the baud rate. Screen timeout: 30 s ECB-VAVS Preloaded Applications...

  • Page 46: How To Calibrate The Sensor And Adjust The Screen Contrast

    6. Press the Menu button once you have finished viewing the Device ID. Screen timeout: 30 s The Allure EC-Smart-Vue’s hardware information may be required by Distech Controls Technical Sup- port for troubleshooting purposes. How to Calibrate the Sensor and Adjust the Screen Contrast The General Configuration submenu also allows the calibration of the Allure EC-Smart-Vue’s space...

  • Page 47: How To Exit The Submenu

    How to Exit the Submenu Press the Menu button several times until the Exit screen appears. Then press either of the arrow £ keys. Screen timeout: 30 s Press and hold the Menu button for 5 seconds. £ ECB-VAVS Preloaded Applications...

  • Page 48: Configuring The Vav

    Allure EC-Smart-Vue Screen-by-Screen Guide Configuring the VAV The VAV configuration parameters of an ECB-VAVS controller can be found in the VAV Configuration submenu of the Advanced menu. Through this submenu, various selections can be made, such as a controller’s fan powered box type, number of duct heater reheat stages, and VVT operation mode.
  • Page 49 How to Exit the Submenu Press the Menu button several times until the Exit screen appears. Then press either of the arrow £ keys. Screen timeout: 30 s Press and hold the Menu button for 5 seconds. £ ECB-VAVS Preloaded Applications...
  • Page 50 30 seconds drive time 50 S 50 seconds drive time 60 S 60 seconds drive time Drive time controlled by Custom CustomFloatTime 25.5 0.1 to 25.5 seconds Pule Width Modulation Valve PWMVLV Period 0.1 to 5.2 seconds ECB-VAVS Preloaded Applications...

  • Page 51: Setting Up Inputs

    3. Press the Menu button to submit the password. Screen timeout: 15 s Upon submitting the correct password, the advanced menu is displayed. press several times Screen timeout: 15 s 4. Press the Menu button several times until IN CFG appears on the display. ECB-VAVS Preloaded Applications...
  • Page 52 How to Exit the Submenu Press the Menu button several times until the Exit screen appears. Then press either of the arrow £ keys. Screen timeout: 30 s Press and hold the Menu button for 5 seconds. £ ECB-VAVS Preloaded Applications...
  • Page 53 Cooling and Heating Setpoint via EC- DUAL EC-Smart-Vue User Setpoint Smart-Vue COMSENS SP Control OFFS Room Temperature Setpoint Offset 10-2 Sensors are 10K Type II Discharge and Space Temp SENSORS TYPE Sensors Type 10-3 Sensors are 10K Type III ECB-VAVS Preloaded Applications...

  • Page 54: Setting Up Outputs

    Upon submitting the correct password, the advanced menu is displayed. press several times Screen timeout: 15 s 4. Press the Menu button several times until OUT CFG appears on the display. 5. Press either of the arrow keys to enter the Output Configuration submenu. ECB-VAVS Preloaded Applications...

  • Page 55: How To Exit The Submenu

    How to Exit the Submenu Press the Menu button several times until the Exit screen appears. Then press either of the arrow £ keys. Screen timeout: 30 s Press and hold the Menu button for 5 seconds. £ ECB-VAVS Preloaded Applications...

  • Page 56: Output Wiring (Vavs)

    Suppose Heat 1 Type is an analog 0-10V signal and Heat 2 Type is PWM Triac. In this case, Analog output 4 of the controller is used to control heat source 1 and Digital output 2 of the controller is used to control heat source 2. ECB-VAVS Preloaded Applications...

  • Page 57: Configuring The Flow Setpoint Parameters

    Upon submitting the correct password, the advanced menu is displayed. press several times Screen timeout: 15 s 4. Press the Menu button until the FLOWSP menu appears on the display. Screen timeout: 30 s The minimum flow (MIN) parameter appears. ECB-VAVS Preloaded Applications...

  • Page 58: How To Exit The Submenu

    How to Exit the Submenu Press the Menu button several times until the Exit screen appears. Then press either of the arrow £ keys. Screen timeout: 30 s Press and hold the Menu button for 5 seconds. £ ECB-VAVS Preloaded Applications...

  • Page 59: Performing Vav Airflow Balancing

    5. Press the Menu button several times until the Balancing (BAL) menu appears on the display. Screen timeout: 15 s 6. Press either of the arrow keys to enter the Balancing submenu. Upon entering the Balancing submenu, the K-Factor parameter appears. ECB-VAVS Preloaded Applications...

  • Page 60: How To Perform Airflow Balancing

    The Flow Setpoint parameter appears. 3. Use the arrow keys to override the flow setpoint. Choose a relatively high setpoint. Screen timeout: 5 min 4. Press the Menu button to submit the new flow setpoint. Screen timeout: 5 min ECB-VAVS Preloaded Applications...
  • Page 61 Note that at this point, the K-Factor gets adjusted based on the airflow value just entered. 8. Press the Menu button several times until the K-Factor parameter reappears. This value can be in- cluded in the balancing report. Screen timeout: 5 min The VAV controller is now balanced. ECB-VAVS Preloaded Applications...

  • Page 62: How To Initialize The Damper

    The damper begins the initialization process. During this process, the screen displays -1. Screen timeout: 5 min After a few minutes, the screen redisplays the damper’s current position. Screen timeout: 5 min The damper is now initialized. ECB-VAVS Preloaded Applications...

  • Page 63: Other Functions In The Balancing Submenu

    Screen timeout: 5 min Press the Menu button to submit the new rotation direction. Screen timeout: 5 min To view the current differential pressure reading, navigate to the Pressure parameter. inWC Screen timeout: 5 min ECB-VAVS Preloaded Applications...

  • Page 64: How To Release Overrides

    How to Exit the Submenu Press the Menu button several times until the Exit screen appears. Then press either of the arrow £ keys. Screen timeout: 30 s Press and hold the Menu button for 5 seconds. £ ECB-VAVS Preloaded Applications...

  • Page 65: Performing Overrides

    Upon submitting the correct password, the advanced menu is displayed. press several times Screen timeout: 15 s 4. Press the Menu button several times until OVR appears on the display. Screen timeout: 30 s 5. Press either of the arrow keys to enter the Overrides submenu. ECB-VAVS Preloaded Applications...

  • Page 66: How To Release Overrides

    To manually release an override: 1. Press and hold both arrow keys simultaneously. Screen timeout: 5 min The screen then displays three dashes. 2. Press the Menu button. Screen timeout: 5 min ECB-VAVS Preloaded Applications...

  • Page 67: How To Exit The Submenu

    How to Exit the Submenu Press the Menu button several times until the Exit screen appears. Then press either of the arrow £ keys. Screen timeout: 30 s Press and hold the Menu button for 5 seconds. £ ECB-VAVS Preloaded Applications...

  • Page 68: Configuration Codes

    £ Output Configuration £ This chapter describes the use of codes in speeding up the configuration of ECB-VAVS controllers. Procedure for Submitting New Configuration Codes using an Allure EC-Smart-Vue Using codes to configure a controller saves time, especially when working with large quantities. The following three submenus, in the Allure EC-Smart-Vue’s Advanced menu, can be configured using...

  • Page 69: How To Exit The Submenu

    How to Exit the Submenu Press the Menu button several times until the Exit screen appears. Then press either of the arrow £ keys. Screen timeout: 30 s Press and hold the Menu button for 5 seconds. £ ECB-VAVS Preloaded Applications...

  • Page 70: Tables Of Configuration Codes

    The configuration codes for each controller model are presented in the tables below. But first, an ex- ample is given illustrating how to calculate a configuration code based on the desired configuration pa- rameters. As an example, suppose one wanted to configure the inputs of an ECB-VAVS to have the following characteristics: Input...
  • Page 71 Modulating 0-10V on AO4 2-10V Modulating 2-10V on AO4 Heating1 Normally Close Valve HT1 NORM OPEN Heating1 Normally Open Valve Heating2 Normally Close Valve HT2 NORM OPEN Heating2 Normally Open Valve Default Output Code * DO3 is unused ECB-VAVS Preloaded Applications...
  • Page 72 ECB-VAVS Preloaded_UG_10_EN...
