Variables
CoolingStgsLoad (AV68)
This variable is used to display the percentage of cooling stages active. This variable is used for the
HMI.
ID
Analog Value 68
HeatingStgsLoad (AV69)
This variable is used to display the percentage of heating stages active. This variable is used for the
HMI.
ID
Analog Value 69
ComSensorMinCoolSP (AV75)
This variable is used to calculate the minimum value that can be configured for the occupied cooling
setpoint by the end user from the EC-Smart-Vue. The minimum value is equal to the maximum be-
tween ComSensorMinCoolSp and StandbyHeatSp + 0.7°ΔF (0.4°ΔK)
ID
Analog Value 75
ComSensorMaxCoolSP (AV76)
This variable is used to calculate the maximum value that can be configured for the occupied cooling
setpoint by the end user from the EC-Smart-Vue. The maximum value is equal to the minimum be-
tween ComSensorMaxCoolSp and StandbyCoolSp - 0.5°ΔF (0.2°ΔK)
ID
Analog Value 76

ComSensorMinHeatSP (AV77)

This variable is used to calculate the minimum value that can be configured for the occupied Heating
setpoint by the end user from the EC-Smart-Vue. The minimum value is equal to the maximum be-
tween ComSensorMinHeatSp and StandbyHeatSp + 0.5°ΔF (0.2°ΔK)
ID
Analog Value 77

ComSensorMaxHeatSP (AV78)

This variable is used to calculate the maximum value that can be configured for the occupied Heating
setpoint by the end user from the EC-Smart-Vue. The maximum value is equal to the minimum be-
tween ComSensorMaxHeatSp and StandbyCoolSp - 0.7°ΔF (0.4°ΔK).
ID
Analog Value 78

DischTempCoolSP (AV79)

This variable is used to calculate if another cooling stage is required to cool the space. When the
space temperature is requiring cooling, cooling stages will be turned on only if the discharge tempera-
ture is above DischTempCoolSP(AV79).
ID
Analog Value 79
26
Units
Percent (%)
Units
Percent (%)
Units
Degrees-Celsius (°C)
Units
Degrees-Celsius (°C)
Units
Degrees-Celsius (°C)
Units
Degrees-Celsius (°C)
Units
Degrees-Celsius (°C)
Valid Range
0 to 100%
Valid Range
0 to 100%
Valid Range
N/A
Valid Range
N/A
Valid Range
N/A
Valid Range
N/A
Valid Range
4,5 to 18°C
ECY-303 Preloaded Applications
Default Value
-1%
Default Value
-1%
Default Value
19,5 °C
Default Value
26,7 °C
Default Value
15,5 °C
Default Value
24 °C
Default Value
7°C
