Accessing the ECY-303 with ENVYSION

Accessing the ECY-303 with ENVYSION
You can access the ECY-303 Preloaded Applications through the Xpress Network Utility. Refer to the
Xpress Network Utility User Guide for more information.
You can also access the ECY-303 Preloaded Applications directly through your web browser using the
controller IP address or using the Controller's Factory-default Hostname.
For more information regarding the different ways to access the configuration page, refer to the
ECLYPSE Connected Equipment Controller Hardware Installation Guide.

Logging on to the Web Interface

When logging on to the web interface, you will be prompted to choose the project you would like to
work with, in this case choose the ECY-303_RTU project.
Figure 1: Choose your project when accessing the controller through the Web Interface.

Graphic Page

The ECY-303 Preloaded Applications Graphic Page, similar to the figure below, opens once you enter
the ENVYSION viewer and click the Graphic from the navigation menu on the left.
10 ECY-303 Preloaded Applications
