MaxFanCurrent (AV45)
This variable is used to configure the maximum scaling of UI6 when configured for FanCurrent. The
range of the input can be configured using UI6Range(MSV20).
ID
Analog Value 45
ChgOverDelay (AV46)
This variable is used to configure the minimum delay between heating/cooling.
ID
Analog Value 46
BypassTime (AV47)
This variable is used to configure the bypass delay when the room occupancy is overridden either via
the EC-Sensor-SO, the EC-Smart-Comfort or the EC-Smart-Vue.
ID
Analog Value 47
MaxOatHeat (AV48)
This variable is used to configure the outdoor temperature above which the heating stages are dis-
abled.
ID
Analog Value 48
MinOatHeat (AV49)
This variable is used to configure the outdoor temperature below which the compressor stages are
disabled.
ID
Analog Value 49
EffectSp(AV50)
This variable is used to display the actual setpoint used by the control algorithm. This value is based
on the occupancy status (MSV15) and the actual cooling and heating setpoints (AV36 and AV37)
ID
Analog Value 50
TempErr(AV51)
This variable is used to display the actual deviation of the temperature from the setpoint.
ID
Analog Value 51
CO2Setpoint (AV52)
This variable is used to configure the CO2 setpoint.
ID
Analog Value 52
ECY-303 Preloaded Applications
Units
Amperes (A)
Units
minutes
Units
minutes
Units
Degrees-Celsius (°C)
Units
Degrees-Celsius (°C)
Units
Degrees-Celsius (°C)
Units
Delta-Degrees-Celsius (∆°C)
Units
ppm
Valid Range
N/A
Valid Range
N/A
Valid Range
N/A
Valid Range
N/A
Valid Range
N/A
Valid Range
N/A
Valid Range
N/A
Valid Range
N/A
Variables
Default Value
10 A
Default Value
1 min
Default Value
120 min
Default Value
18°C
Default Value
10°C
Default Value
N/A
Default Value
N/A
Default Value
1000 ppm
