DischTempCoolDB (AV80)

This variable is used to calculate if a cooling stage must be stopped. If the discharge temperature is
below DischTempCoolSP(AV79) – DischTempCoolDB(AV80), a cooling stage is stopped.
ID
Analog Value 80

DischTempHeatSP (AV81)

This variable is used to calculate if another heating stage is required to heat the space. When the
space temperature is requiring heating, heating stages will be turned on only if the discharge tempera-
ture is below DischTempHeatSP(AV81).
ID
Analog Value 81

DischTempHeatDB (AV82)

This variable is used to calculate if a heating stage must be stopped. If the discharge temperature is
above DischTempHeatSP(AV81) + DischTempHeatDB(AV82), a heating stage is stopped.
ID
Analog Value 82

ExhaustStartSP (AV83)

This variable is used to configure the damper position above which the power exhaust is started.
ID
Analog Value 83

ExhaustStopSP (AV84)

This variable is used to configure the damper position below which the power exhaust is stopped..
ID
Analog Value 84

InitStartDelay (AV85)

This variable is used to configure the delay after a reboot of the controller before enabling the con-
troller.
ID
Analog Value 85

DischTempLowLimitSP (AV86)

This variable is used to calculate the LowLimitAlarm(BV17). When the fan is running and the dis-
charge temperature is lower than this value, the low limit alarm is set to alarm mode.
ID
Analog Value 86

SpOffsetRange (AV87)

This variable is used to configure the setpoint offset range of either a remote control or the room sen-
sor.
ECY-303 Preloaded Applications
Units
Delta-Degrees-Celsius (∆°C)
Units
Degrees-Celsius (°C)
Units
Delta-Degrees-Celsius (∆°C)
Units
Percent (%)
Units
Percent (%)
Units
Seconds
Units
Degrees-Celsius (°C)
Valid Range
1 to 5∆°K
Valid Range
26,5 to 65,5°C
Valid Range
1 to 16,5∆°K
Valid Range
0 to 100%
Valid Range
0 to 100%
Valid Range
N/A
Valid Range
0 to 7°C
Variables
Default Value
3∆°K
Default Value
32°C
Default Value
8 ∆°K
Default Value
50%
Default Value
25%
Default Value
120s
Default Value
2°C
