Variables
SpaceHumiditySP (AV53)
This variable is used to configure the space/return humidity setpoint.
ID
Analog Value 53
DehumiditySP (AV54)
This variable is used to configure the space/return dehumidity setpoint to control the cooling stages.
ID
Analog Value 54
DischHumiditySP (AV55)
This variable is used to configure the discharge humidity high limit setpoint.
ID
Analog Value 55
MaxRangeCO2 (AV56)
This variable is used to configure the maximum scaling of UI7 or UI8 when configured for SpaceCO2
o r R e t u r n C O 2 . T h e r a n g e o f t h e i n p u t c a n b e c o n f i g u r e d u s i n g U I 7 R a n g e ( M S V 2 1 ) o r
UI8Range(MSV22)
ID
Analog Value 56
MinRangeCO2 (AV57)
This variable is used to configure the minimum scaling of UI7 or UI8 when configured for SpaceCO2
o r R e t u r n C O 2 . T h e r a n g e o f t h e i n p u t c a n b e c o n f i g u r e d u s i n g U I 7 R a n g e ( M S V 2 1 ) o r
UI8Range(MSV22)
ID
Analog Value 57
ComSensorSpOffset (AV58)
This variable is used to display the actual EC-Smart-Vue or EC-Smart-Comfort setpoint offset value.
ID
Analog Value 58
FanOnSetpoint (AV59)
This variable is used to configure the on trigger value used to calculate a digital fan status when UI6 is
configured for FanCurrent.
ID
Analog Value 59
FanOffSetpoint (AV60)
This variable is used to configure the off trigger value used to calculate a digital fan status when UI6 is
configured for FanCurrent.
24
Units
%RH
Units
%RH
Units
%RH
Units
ppm
Units
ppm
Units
Delta-Degrees-Celsius (∆°C)
Units
Amperes (A)
Valid Range
5 to 55%RH
Valid Range
40 to 95%RH
Valid Range
50 to 95%RH
Valid Range
N/A
Valid Range
N/A
Valid Range
- AV87 to AV87
Valid Range
>0A
ECY-303 Preloaded Applications
Default Value
35%RH
Default Value
55%RH
Default Value
85%RH
Default Value
2000ppm
Default Value
0ppm
Default Value
0∆°C
Default Value
1 A
