Chapter 4: BIOS Setup
NCT6793D Super IO Configuration
This section is used to configure the serial ports.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Advanced
NCT6793D Super IO Configuration
Super IO Chip NCT6793D
Serial Port 1 Configuration
Serial Port 2 Configuration
Version 2.18.1263. Copyright (C) 2019 American Megatrends, Inc.
Super IO Chip
Displays the Super I/O chip used on the board.
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Serial Port 1 Configuration
Set Parameters of Serial Port
2 (COMB)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Serial Port
Enables or disables the serial COM port.
Device Settings
Displays the IO address and IRQ of the serial COM port.
Onboard Serial Port Mode
Select this to change the serial port mode to RS232, RS422, RS485 No
Terminator or RS485 With Terminator.
34
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Advanced
Serial Port 1 Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4;
Onboard Serial Port Mode [RS232]
Version 2.18.1263. Copyright (C) 2019 American Megatrends, Inc.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
