Chapter 1: Product Introduction

Hardware Specifications

Panel
▪ LCD size: Innolux G-series 21.5", 16:9
▪ Resolution: Full HD 1920 x 1080
▪ Luminance
– LCD panel: 400 cd/m 2
– XPPC PCAP touch: 85% of panel's luminance after air bonding
▪ Contrast ratio: 1000
▪ LCD color: 16.7M
▪ Viewing angle: 89 (U), 89 (D), 89 (L), 89 (R)
Touch Screen
▪ 10 points P-Cap (projected capacitive touch)
▪ Glass surface treatment: AS + AG
System
– CPU: onboard Intel Celeron
®
– Graphic: Intel HD graphics
®
Main Memory
▪ 1 x SO-DIMM socket support up to 8GB DDR3L 1866 MHz, non-ECC
and un-buffered memory
Storage Device
▪ 1 x M.2 M key 2242 SSD (support SATA 3.0)
Expansion
▪ 1 x mini-PCIe full-size connector with SIM slot (full-size) onboard,
support Wi-Fi/LTE module
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
processor J3455, 1.50GHz, 2M cache
®
Rear I/O
▪ 1 x COM1: RS232/422/485
▪ 1 x 19V DC-in power jack lock type
▪ 2 x RJ45 with LEDs for Gigabit LAN
▪ 1 x HDMI 2.0, resolution 4096 x 2160 60Hz
▪ 2 x USB 3.0
▪ 1 x Line-out
▪ LED for power on/off
▪ Power switch
Front I/O
▪ 2 x Antenna holes
Mechanical
▪ Color/material: black silver/metal sheet
▪ Support
– VESA mount 100mm x 100mm
– Panel mount
– Open frame
Environment
▪ Vibration
– IEC 60068-2-64
– 2Grms @ sine, 5~500Hz, 1hr/axis
– 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating)
▪ Shock
– IEC 60068-2-27
– 50g peak acceleration (11 msec. duration)
▪ Temperature
