Chapter 1: Product Introduction
– Operating temperature with 0.7 m/s air flow: 0°C~45°C
(optional to 50°C)
– Storage temperature: -20°C~60°C
▪ Operating humidity: 10%~90% relative humidity, non-condensing limits
to be at 90%
Dimensions
▪ System: 520.6mm x 315.6mm x 54mm
▪ System weight: 5.0kg
▪ Package: 650mm x 480mm x 170mm
▪ Package weight: 7.5kg
Power Supply
▪ 1 x 90W AC/DC lockable adapter included in accessory
▪ Input: 100VAC to 240VAC
▪ Output: DC+19VD
Certification
▪ CE (EN55035 + EN55032)
▪ FCC Class A (EMI part 15B)
▪ LVD (EN62368-1)
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Operating System Support
▪ Windows 10 64-bit
▪ Linux
3
XPPC 22-100A User Manual
