Chapter 2: Jumpers and Connectors
Debug Port/LPC Bus Connector
Connector type: 1x10 10-pin header, 1.0mm pitch
Connector location: NXM_DEBUG
10
1
Pin
Definition
1
+3V
3
LAD0
5
LAD2
7
LFRAME#
9
PLTRST#
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
SERIRQ
4
LAD1
6
LAD3
8
25MHZ
10
GND
COM Port Connector
Connector type: 1x9 9-pin header, 1.0mm pitch
Connector location: COM2
9
1
Pin
Definition
1
DCD
3
TXD
5
GND
7
RTS
9
RI
19
Pin
Definition
2
RXD
4
DTR
6
DSR
8
CTS
XPPC 22-100A User Manual
