Chapter 2: Jumpers and Connectors
Jumpers & DIP Switches

AT/ATX Mode Select

Connector type: 1x3 3-pin header, 2.0mm pitch
Connector location: ATX_AT
1 1 3 3
Pin Settings
1-2 On ATX Mode
2-3 On AT Mode
1-2 On: default
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.

Clear CMOS

Connector type: 1x3 3-pin header, 2.0mm pitch
Connector location: CLRTC
1 1 3 3
Pin Settings
1-2 On Normal
2-3 On Clear CMOS
1-2 On: default
