3-2 Disk drive overview
Figure 3-1
Disk drive mounting details (typical)
Top view
Do not remove
Side view
297-1001-537 Standard 01.02 December 1993
Do not remove
Do not remove
Guide bracket
Retainer screw
Extraction handle
Retainer screw
Extraction
handle
reference
Retainer
screw
reference
Front view
