Procedure 6-12
Recover AMA data from DIRP - DIRP block number not known
Step Description
1 Contact the data center and determine the
time frame of the missing AMA, the
sequence number of the last DPP block the
data center received before the DPP outage,
and the first sequence number received
following the DPP outage. The sequence
numbers referred to here are DPP reference
numbers, not DMS or Data Center assigned
numbers.
At the MAP enter the following commands to
see if the DPP sequence numbers are
available to display from the DPP disk:
>MAPCI NODISP;MTC;IOD;DPPAMA
>RECORD START ONTO <printer>
>IDXMAINT EXAMINE AMA PACKED
<first seq number>
>IDXMAINT EXAMINE AMA PACKED
<last seq number>
If the above commands are successful, the
DPP outputs the requested AMA data
blocks. If BOTH blocks, first and last, were
printed out, continue to step 2. Any blocks
not output by the IDXMAINT command must
be provided by the data center before
continuing.
2 From each of the blocks of AMA data, one
record is required. In one block, locate an
"AA." Immediately following the "AA" is a
Structure Code. Using an NTP, break the
record down into the individual fields that
make up a record. For BCS31 or above,
use NTP 297-1001-830. For BCS30 and
below, use NTP 297-1001-128. An
example is below.
07BA 0000
0602 091C
0780 1C1C
301C 0000
Automatic message accounting (AMA) messages 6-17
0040 0000 AA00
0021 3C00 000C
0060 2C83 8579
0023 0C00 0838
(continued)
DPP Recovery and Routine Maintenance Guide BCS35 and up
Notes
The first seq number may not be available
depending on the specific DPP fault.
If NTP 297-1001-830 is not available, NTP
297-1001-128 can be used to decipher
most records regardless of the BCS level.
700C 043C 036C
0200 000C 1C0C
2C00 0015 2C00
8C
0602 091C 036C
1C00 0C60 2C82
0000 000C 1010
