Northern Telecom DMS-100 Series General Description, Installation And Maintenance

Digital switching systems
Hide thumbs Also See for DMS-100 Series:

Advertisement

Quick Links

Download this manual
NORTHERN TELECOM
Printed in Canada
DIGITAL SWITCHING SYSTEMS
DMS-100* FAMILY
INTEGRATED BUSINES
NETWORK SERVICE
BUSINESS SET, GENERAL DESCRIPTION,
INSTALLATION,
Maintenance and Ordering Information
CONTENTS
Reason for Reissue: This revised issue replaces the Standard issue dated
86-05-27. The revisions include the addition of Automatic Call Distribution
(ACD) Sets, incorporation of Appendix 1 (Business Sets and Handsets
equipped with TELADAPT* connectors) and numerous other information
updates and corrections. Due to the substantial changes which require
repagination and renumbering of illustrations, revision marks would not be
helpful and are, therefore, not used in this Practice revision.
* DMS-100 is a trademark of Northern Telecom.
© Northern Telecom 1985
PRACTICE 297-2011-200
Issued: 88 12 08
Standard
REL.NO. 01.02
PAGE
Page i
